Technical Data
14
Example 2:
Feed material:
Wood pellets (< 5 mm)
Bottom sieve:
0.5 mm
Speed:
4 000 rpm
At these operating conditions, the workplace related equivalent continuous sound level
L
eq
= 75.1 dB(A).
3.4 Electromagnetic Compatibility (EMC)
− EMC class according to DIN EN 55011: B
3.5 Rated Power
~ 1 500 W (VA)
3.6 Motor Rotation Speed
− Rated motor rotation speed: 2 000 – 4 000 revolutions per minute (rpm)
− Adjustable in increments of 200 rpm
3.7 Dimensions and Weight
All specifications, unless otherwise stated, include the optional base frame.
− Height: 1 200 mm
− Height incl. vibratory feeder DR 100: ~ 1 450 mm
− Width: 580 mm
− Width incl. cyclone separator: 930 mm
− Depth: 700 mm
− Weight: ~ 60 kg
− Weight without base frame: ~ 50 kg
3.8 Required Floor Space
CAUTION
C5.0007
Falling down of the device
Incorrect positioning or insufficient working space
− Due to its weight, the device can inflict personal injury if it falls down.
• The device must, when used as table-top device, only be operated on
a sufficiently large, strong and stable workplace.
• The device must, when used as table-top device, be firmly screwed
to the working surface.
− Width with open door: ~ 740 mm
− Depth with open door: ~ 640 mm
− Width of the base: 940 mm (without cyclone separator)
1 130 mm (with cyclone separator)
− Depth of the base: 740 mm (without base frame)
800 mm (with base frame)
