Fig. 33: Rear side of the vibratory feeder DR 100
Plug the power cable into the mains connection on the rear.
Set the operating mode selector switch (DR3) to "Standard". A control via "Extern" (external)
is not possible in conjunction with the SK 300.
Turn on the vibratory feeder DR 100 via the rear mains switch (DR4).
For detailed information on the controls, please refer to the manual of the vibratory feeder
DR 100.
12.2 Cyclone Separator
High risk of injury from spinning rotor
Operating any machinery without safety guards in place
− If the device is operated without safety guards in place (discharge
flange), clothing or parts of the body can be drawn into the grinding
chamber. The spinning rotor can cause serious injuries.
• Never operate the device without all safety guards in place!
