Revv Owner’s Manual - 34
Revv Generator 100w Continuous Controller Commands (CC)
In order to use CC commands, the Generator Functions have all been
given a designated number & on or off setting. When using & selecting a
function the number associated with the function must be used & then
the setting of the function (on or off) must also be sent. Most MIDI equip-
ment (pedals etc) allows you to select a CC number & then designate
whether it be turned to on or off. (Consult the external equipments’
instruction manual). The following commands & their CC numbers need
only be sent an on command (0-63) as they are used to switch between
channels & aggression levels which cannot be turned off, only changed
to a different channel or level, on & off commands sent will produce the
same result.
Function + CC Number (Hex Value)
Channel 1 Clean - 16 - (0×10)
Channel 1 Crunch - 17 - (0×11)
Channel 2 low aggression - 18 - (0×12)
Channel 2 medium aggression - 19 - (0×13)
Channel 2 high aggression 20 - (0×14)
The following command will switch to the channel & then toggle through
the aggression levels with each use of the command like using the
footswitch to switch to the channel & toggle through the aggression
levels. This command will also respond to an on & off command with the
same result:
Channel two plus aggression toggle: 24 – (0x18)
6.5
