Revv Owner’s Manual - 36
Foot Switch
The Revv footswitch can be configured to either operate as a normal
footswitch (with some bonuses) or a tool to quickly recall presets on the
amplifier.
Control Mode - select between clean, crunch, & gain channels, gain
aggression modes, fx loop on/off, master volumes, & a master mute func-
tion
Preset Mode - select combinations of channel & switch positions +
master volume select & FX Loop on/off that can be recalled with one
button press.
Note: The footswitch will always be updated should a change be made
on the amplifier front panel. Panel controls override the footswitch.
Note: To switch between modes, press & hold footswitch button 1 for 2
seconds. The LEDs will all illuminate then switch to the settings in the
other mode. All settings will be retained when switching between modes.
Hook up
The footswitch is connected to the rear of the amplifier with a shielded
Ethernet cable & very rigid connectors. The amplifier & footswitch will
work with any Ethernet cable should you be in a pinch, but the Revv
cable is always recommended for best performance.
It is recommended that the footswitch be connected to the amp with the
power off, but should you plug it in during amplifier use, it will power up &
automatically set itself to the amps current settings. Upon power up, all
LEDs will turn on for a couple of seconds as it initializes. Once complete,
the foot pedal will set itself to the amplifier’s current configuration.
7.0
7.1
