REXON SM2158R - Aligning the Laser Beam; Laser Line Alignment Check

13
● Do not attempt to repair or
disassemble the laser. If
unqualied persons attempt to
repair this laser product, serious
injury may result. Any repair
required on this laser product
should be performed by a
qualied service dealer.
A. Checking Laser Line Alignment
(Fig. 19, 20)
1. Set the saw to a 0° miter and 0°
bevel setting.
2. Use a combination square to mark
a 90° angled running across the top
and down the front of a board. This
line will serve as the pattern line to
adjust the laser. Place the board on
the saw table.
3. Carefully lower the saw head
down to align the saw blade with
the pattern line. Position the saw
blade to the left, center or right side
of the “pattern line” depending on
your preference for the laser line
location. Lock board in place with
hold-down clamp.
4. With the saw plugged in, turn on
the laser guide. Your saw has been
preset with the laser line to the left
side of the blade.
5. Slide the cutting head forward
enough so that the laser line is
visible on the front of the board.
WARNING! When making laser line
adjustments, keep ngers away from
the ON/OFF trigger switch to prevent
accidental starting and possible
serious injury.
ALIGNING THE LASER BEAM
(FIG. 19, 20, 21, 22)
The laser beam must always be
correctly aligned with the blade to
ensure straight, even cutting.
Your tool is equipped with the laser
guide using Class IIIa laser beam. The
laser beam allows you to preview the
saw blade path on the stock to be cut
before starting the miter saw. This laser
guide is powered by the transformed
alternating current supply directly
through the power lead. The saw must
be connected to the power source
and the laser ON/OFF rocker switch
must be turned on for the laser line
to show.
WARNING! For your own safety,
never connect the plug to power
source outlet until all the adjustment
steps are complete and you have
read and understood the safety and
operational instructions.
WARNING! AVOID DIRECT EYE
CONTACT
● Laser radiated when laser guide
is turned on. Avoid direct eye
contact.
● Laser Warning Label:
Max output <5 mW Wavelength:
630-660 nm, Complies with
21CFR 1040.10 and 1040.11 Class
IIIa Laser Product.
● Use of controls or adjustments
or performance of procedures
other than those specied herein
may result in hazardous radiation
exposure.
● The use of optical instruments
with this product will increase
eye hazard.
