REXON SM2158R - Installation; Know Your Miter Saw

7
WARNING! Noise can be a health
hazard. When the noise level
exceeds 80 dB(A), be sure to wear
ear protection.
ENVIRONMENTAL PROTECTION
Waste electrical products
should not be disposed of
with household waste. Please
recycle where facilities exist.
Do not dispose of electrical appliances
as unsorted municipal waste, use
separate collection facilities. Contact
your local government for information
regarding the collection systems
available. If electrical appliances are
disposed of in landlls or dumps,
hazardous substances can leak into
the groundwater and get into the
food chain, damaging your health
and wellbeing. When replacing old
appliances with new once, the retailer
is legally obligated to take back your
old appliance for disposal at least for
free of charge. Disposal of discarded
material shall be in accordance with
local environmental regulations.
Wear safety goggles
Wear ear protection
Wear a breathing mask
Keep hands away from blade:
Failure to keep your hands
away from the blade will result
in serious personal injury.
Read and understand
instruction manual: to reduce
the risk of injury, user and all
bystanders must read and
understand instruction manual
before using this product.
Installation
KNOW YOUR MITER SAW (FIG. 1)
1. Laser horizontal adjustment knob
2. Laser vertical adjustment knob
3. Lower blade guard
4. Extension table lock knob
5. Table insert
6. Miter handle
7. Positive stop locking lever
8. Base
9. Positive miter detent
10. Table
11. Extension table
12. Stop plate
13. Fence locking lever
14. Slide fence
15. Slide carriage lock knob
16. Upper blade guard
17. Slide carriage
18. Bevel lock knob
19. Mounting hole
20. Motor
21. Blade
22. Quick-cam locking lever
23. Switch handle
24. Carrying handle
25. Exhaust port
26. Cutting depth adjusting knob
27. Hold-down latch
