REXON SM2158R - Figures 18 - 23

24
2 1
FIG. 18 FIG. 21
FIG. 19 FIG. 22
FIG. 23
FIG. 20
1
Laser line
Pattern line
Counterclockwise Clockwise
Counterclockwise Clockwise
Laser line
Pattern line
1
4
3
2
5
6
7
8
9
1. Miter saw base
2. Hex head bolt
3. Rubber washer
4. Flat washer
5. Workbench
6. Flat washer
7. Lockwasher
8. Hex nut
9. Jam nut
TOP VIEW
Laser line
Cutting line
Blade
Laser line
Workpiece
Cutting
line
