INSTALLING THE MITER HANDLE
(FIG. 3)
1. Insert the miter handle (1) into the
hole (2) in front of the miter saw and
align the hole on the miter handle (1)
with the hole (2) in the front of the
table.
2 Thread the screw (4) through the
hole (3) in the table into the hole (2)
on the miter handle (1).
3. Tighten the screw (4) with a
screwdriver.
INSTALLING THE DUST BAG (FIG. 4)
Install the dust bag assembly (1)
onto the exhaust port (2) on the miter
saw. Fit the connecting tube of dust
bag assembly and the exhaust port
together.
NOTE:
● The dust bag assembly should be
angled toward the right side of the
saw for best results. This will also
avoid any interference during the
saw operation.
● To empty the dust bag, pull out the
dust bag assembly from exhaust
port. Open zipper on underside of
bag and empty into waste container.
IMPORTANT : Check frequently and
empty bag before it gets full.
INSTALLING THE HOLD-DOWN
CLAMP (FIG. 5, 6)
1. Place the hold-down clamp
assembly (1) in one of the mounting
holes (2-Fig. 6) located behind the
fence. (Fig. 5)
WARNING! Do not use this saw to cut
and/or sand metals. The hot chips or
sparks may ignite sawdust from the
bag material.
WARNING! To avoid possible
personal injury or damage to the
miter saw due to tipping, do not
operate the saw without the rear
extension support bar.
NOTE: There are no screws to
secure clamp. The clamp will secure
itself to the base when turning the
knob (3) to clamp the workpiece. Do
not use your other hand to hold the
clamp when tightening. (Fig. 5)
INSTALLING THE REAR EXTENSION
SUPPORT BAR (FIG. 7)
Align the rear extension support bar (1)
with the two holes (2) under the rear
base, and tighten with two screws (3)
by using a Philip screwdriver.
UNLOCKING THE SLIDE CARRIAGE
(FIG. 8)
After removing the saw from the carton,
loosen the slide carriage lock knob (1),
located on the left side of the slide
carriage. When transporting or storing
the miter saw, the slide carriage should
always be locked in position.
SAW BLADE WRENCH (FIG. 9)
1. For convenient storage and
prevention of loss, there is a slot (1)
in the right side of switch handle (2)
for storing the blade wrench (3)
when not in use.
