SM2158R PARTS LIST
ORDER ONLY BY MODEL NUMBER AND PART NUMBER
I.D. NO. DESCRIPTION SIZE Q’TY I.D. NO. DESCRIPTION SIZE Q’TY
082J CUSHION 6# 1 0KDW CR. RE. PAN HD. SCREW M6*1.0-20 2
082L BOLT 1 0KL1 CR.RE. PAN HD. ROUND M6*1.0-12 1
082P SCREW STOP 1 NECK SCREW
082Q LOCK NUT 1 0KMS HEX. NUT M6*1.0 T=5 2
083Z CORD CLAMP 1 0KQW LOCK NUT M5*0.8 T=5 1
0CES COMPRESSION SPRING 1 0KQX NUT M6*1.0 T=6 3
0CR8 SHAFT 1 0KQY LOCK NUT M8*1.25 T=8 1
0D9A ANCHOR BLOCK 1 0KR0 NUT
M12*1.75 T=12
1
0DHY ARBOR COLLAR 2 0KR2 LUCK NUT M5*0.8 T=5 2
0DVJ BLADE WRENCH 1 0KR3 LOCK NUT M6*1.0 T=6 1
0F1H COLLAR 1 0KTS CABLE CLAMP 1
0J4E FLAT WASHER Φ6*13-1 1 0KUW TERMINAL 4
0J4F FLAT WASHER Φ8X16-2.5 1 0LU3 LIMIT SWITCH 1
0J4M FLAT WASHER Φ12*21-1 1 0S1S COLLAR 1
0J6P FLAT WASHER Φ6*16-2 1 20PL CLAMP HANDLE #6 1
0J7K FLAT WASHER
3/8*29/32-5/64
1 224U ROLL PIN 1
0JB0 WAVE WASHER 2 23NX GUARD-CORD 1
0JBB WAVE WASHER 1 26LU WARNING LABEL 1
0JBG DISC SPRING WASHER 1 27JS POWER CABLE 1
0JC8 SPRING PIN 1 27PF COMPRESSION SPRING 1
0JCT SPRING PIN 2 27PQ ROLL PIN 1
0JE7 C-RING 1 290M CAUTION LABEL 1
0JMP O-RING 1 2B7H HEX. SOC. SET SCREW M6*1.0-12 1
0JNR O-RING ROD 1 2BGV NEEDLE POINTER 1
0JPF HEX. HD. BOLT M6*1.0-25 2 2BGW SLIDE PLATE 3
0JUJ HEX. SOC. HD. CAP BOLT M6*1.0-12 1 2BLQ HEX.SOCKET HD.CAP SCREWS M5*0.8-40 2
0JVD HEX. SOC. HD. CAP BOLT M5*0.8-35 1 2BQA BLADE HOLDER 1
0JZC HEX. SOC. SET SCREW M5*0.8-12 1 2CD2 COMPRESSION SPRING 1
0JZF HEX. SOC. SET SCREW M6*1.0-10 2 2E35 TRIGGER 6# 1
0JZN ARBOR BOLT M8*1.25-20 1 2F39 CLEVIS PIN 1
0K05 HEX. SOC. TRUSS HD. SCREW M8*1.25-20 4 2FLY PLUNGER HANDLE 6# 1
0K29 HEX.SOCKET HD.CAP SCREWS 2 2MMC CR.-RE. TRUSS HD. SCREW M5*0.8-6 3
0K30 HEX. SOC. TRUSS HEAD M6*1.0-16 2 2N7W BRACING PLATE 1
& WASHER ASSEMBLY 2RST CENTER SHAFT 1
0K5D CR. RE. COUNT HD. SCREW 1 2T83 TORSION SPRING 1
0K74 CR.-RE. TRUSS HD. SCREW 1 2T9B ROCK SWITCH ASS’Y 1
0KA9 CR.RE. PAN HD. TAPPING SCREW M3*24-10 1 2T9P CAUTION LABEL 1
0KB7 CR.RE. PAN HD. TAPPING SCREW M4*18-16 2 2TGY CR.RE. PAN HD. SCREW M6*1.0-80 3
0KBG CR.RE. PAN HD. TAPPING SCREW M4*18-30 6 & WASHER
0KDH CR. RE. PAN HD. SCREW M5*0.8-8 2 2VN7 BLANKET WASHER 4
0KDJ CR. RE. PAN HD. SCREW M5*0.8-12 1 2VVP KNOB M5*0.8-25 1
0KDK CR. RE. PAN HD. SCREW M5*0.8-16 2 2VS0 LEAD WIRE ASS’Y 1
0KDU CR. RE. PAN HD. SCREW M6*1.0-12 2 2VZ1 RUBBER INSERT 6# 8
