28
SM2158R SAW PARTS LIST
ORDER ONLY BY MODEL NUMBER AND PART NUMBER
I.D. NO. DESCRIPTION SIZE Q’TY I.D. NO. DESCRIPTION SIZE Q’TY
2YR6 SPRING GUARD 1 3H96 CUTTER SHAFT GUARD 1
31VX CR. RE. TRUSS HD. ROUND M6*1.0-14 1 3H98 SEGMENT HANDLE 6# 1
NECK SCREW 3H99 MITER BAR 1
32YX LEAD WIRE ASS’Y 1 3H9A CABLE SHIELD 6# 1
349F PLATE(RIGHT) 1 3H9C KNOB 1
349G PLATE(LEFT) 1 3H9D SHAFT 1
34NJ UPPER TUBE 2 3H9F TILT POINTER 1
34NK UPPER TUBE 2 3H9M SHAFT-PIVOT 1
3527 CLAMP HANDLE # 1 3HHM CR. RE. COUNT HD. SCREW M4*0.7-8 4
35QJ LEVER 1 3HHN CR. RE. COUNT HD. SCREW M5*0.8-12 4
37B5 CONTROLLER ASS’Y 1 3HHS CR.-RE. TRUSS HD. SCREW M4*0.7-10 6
37TF WAVE WASHER 2 3HHV CR. RE. ROUND WASHER M5*0.8-16 2
38TW MOTOR HANDLE 1 HD. SCREW
39DG TRADEMARK LABEL 1 3HJ5 CR. RE. PAN HD. SCREW M5*0.8-6 2
3AZ7 CR. RE. PAN HD. SCREW M5*0.8-16 2 3HJY LOCK NUT M6*1.0 T=9 1
3CMC CR. RE. TRUSS HD. ROUND M6*1.0-15 1 3J9N MITER BAR 1
NECK SCREW 3JE7 HEX.SOCKET HD.CAP SCREWS M5*0.8-20 1
3DJ9 FRAME ENDCAP,BLACK PLASTIC 6# 2 3JEM MOTOR ASS’Y 1
3DJA WASHER BEARING 6# 1 3JET VISE ASS’Y 1
3DJG SPACER 1 3JF0 LASER ASS’Y 1
3DL5 KNOB KR# 1 3JF6 LASER COVER (LEFT) 1
3DMM BEARING COVER 3 3JF7 LASER COVER (RIGHT) 1
3DTZ RUBBER PAD 6# 1 3JFJ PLUG-BUTTON 2
3DWT LASER INSERT 1 3JHS MOTOR HANDLE(DOWN) 1
3DXM LINEAR MOTION BEARING 2 3K0U ANCHOR PLATE 1
3FM3 SPECIAL BOLT 1 3K0V CR. RE. TRUSS HD. ROUND M6*1.0-10 1
3FT4 WARNING LABEL 1 NECK SCREW
3FT6 CAUTION LABEL 1 3K8E BRACKET 1
3G0U CLAMP BOLT 6# 1 3KK4 CR.-RE. TRUSS HD. SCREW M5*0.8-10 1
3G0W CLAMP BOLT 6# 1 3KK8 ARM 1
3G12 LOCKING HANDLE ASS’Y HT# 1 3KM2 LEAD WIRE ASS’Y 1
3G4R BAG-DUST ASS’Y 1 3KP9 LEVER 1
3GFK FLAT WASHER Φ6*12-1 2 3KPA LEVER BRACKET 1
3GGC COMPRESSION SPRING 1 3KWV SHAFT SLEEVE 6# 1
3H8S BASE 1 3M5S CR.RE. PAN HD. TAPPING SCREW M4*18-12 2
3H8T TABLE 1 3ME7 BLADE 1
3H8U ARM-MITER 1 3MJK INSTRUCTION MANUAL 1
3H8V EXTENSION WING 1 3MK2 WARNING LABEL 1
3H8W EXTENSION WING 1 3MK3 LABEL 1
3H8X FENCE 1 3MK4 TILTING SCALE 1
3H8Y ASSIST-FENCE 1 3MK5 TRADE-MARK LABEL 1
3H90 SLIDE-BAR SEAT (FRONT) 1 3MK6 TILTING SCALE 1
3H94 TABLE INSERT HT# 2 3MK7 LASER STICKER 1
3H95 PC-GUARD 1 3MK8 WARNING LABEL 1
