30
SM2158R MOTOR PARTS LIST
ORDER ONLY BY MODEL NUMBER AND PART NUMBER
I.D. NO. DESCRIPTION SIZE Q’TY
0HV2 BALL BEARING 1
0HX7 NEEDLE ROLLER BEARING 1
0JCD SPRING PIN 1
0JX2 HEX. SOC SET SCREW M5*0.8-6 2
0K43 CR. RE. PAN HD. SCREW & WASHER M5*0.8-16 3
0KCQ CR. RE. PAN HD. TAPPING SCREW & WASHER M5*12-65 2
0QBE BRUSH HOLDER ASS’Y 6# 2
0QBH CARBON BRUSH ASS’Y 2
0QBK BRUSH COVER 2
0QGR COMPRESSION SPRING 1
2BMX FLOW GUIDE 6# 1
2BMY ARMATURE ASS’Y 1
2BN1 MOTOR COVER 6# 1
2DW9 WAVE WASHER 1
36SD FIELD ASS’Y 1
3H92 GEAR BOX 1
3JFK CLEVIS PIN 1
3JGV CUTTER SHAFT ASS’Y 1
To Next Page
