8
UBXC-UDXC-IOM (01-24) 1042980-0
Table 2. Heater Throw Distance (Model UBXC)
H*
(Feet
(Meters))
Distance* or Angle
Medium Speed
60°F (33°C)
Rise
Unit Size (MBTUh)
30 45 60 75 100 125 150
Feet (Meters)
5 (1.5)
X 7 (2.1) 9 (2.7) 12 (3.7) 11 (3.4) 11 (3.4) 12 (3.7)
—
Y 16 (4.9) 21 (6.4) 28 (8.5) 27 (8.2) 27 (8.2) 29 (8.8)
Z 43 (13.1) 60 (18.3) 91 (27.7) 84 (25.6) 86 (26.2) 96 (29.3)
Downward louver angle 24° 15° 13° 11° 13° 10°
8 (2.4)
X 9 (2.7) 11 (3.4) 16 (4.9) 15 (4.6) 15 (4.6) 16 (4.9) 13 (4.0)
Y 16 (4.9) 23 (7.0) 30 (9.1) 29 (8.8) 28 (8.5) 31 (9.4) 24 (7.3)
Z 38 (11.6) 57 (17.4) 89 (27.1) 82 (25.0) 83 (25.3) 94 (28.7) 74 (22.6)
Downward louver angle 38° 26° 21° 19° 21° 18° 28°
10 (3.0)
X 8 (2.4) 13 (4.0) 17 (5.2) 16 (4.9) 17 (5.2) 18 (5.5) 13 (4.0)
Y 14 (4.3) 22 (6.7) 30 (9.1) 30 (9.1) 29 (8.8) 32 (9.8) 22 (6.7)
Z 33 (10.1) 54 (16.5) 86 (26.2) 79 (24.1) 81 (24.7) 92 (28.0) 62 (18.9)
Downward louver angle 48° 32° 26° 25° 26° 23° 35°
12 (3.7)
X 8 (2.4) 13 (4.0) 18 (5.5) 17 (5.2) 17 (5.2) 19 (5.8) 13 (4.0)
Y 12 (3.7) 21 (6.4) 31 (9.4) 30 (9.1) 29 (8.8) 32 (9.8) 21 (6.4)
Z 28 (8.5) 51 (15.5) 83 (25.3) 77 (23.5) 78 (23.8) 89 (27.1) 57 (17.4)
Downward louver angle 56° 39° 31° 30° 32° 27° 42°
14 (4.3)
X
—
12 (3.7) 18 (5.5) 18 (5.5) 18 (5.5) 20 (6.1) 12 (3.7)
Y 20 (6.1) 30 (9.1) 29 (8.8) 29 (8.8) 32 (9.8) 19 (5.8)
Z 46 (14.0) 79 (24.1) 74 (22.6) 74 (22.6) 87 (26.5) 51 (15.5)
Downward louver angle 46° 36° 34° 37° 32° 49°
16 (4.9)
X
—
11 (3.4) 19 (5.8) 18 (5.5) 18 (5.5) 20 (6.1) 11 (3.4)
Y 17 (5.2) 29 (8.8) 28 (8.5) 27 (8.2) 31 (9.4) 16 (4.9)
Z 40 (12.2) 75 (22.9) 70 (21.3) 70 (21.3) 83 (25.3) 43 (13.1)
Downward louver angle 53° 41° 39° 42° 36° 57°
18 (5.5)
X
—
17 (5.2) 18 (5.5) 17 (5.2) 20 (6.1)
—
Y 28 (8.5) 26 (7.9) 26 (7.9) 30 (9.1)
Z 69 (21.0) 65 (19.8) 64 (19.5) 78 (23.8)
Downward louver angle 46° 44° 47° 40°
H*
(Feet
(Meters))
Distance* or Angle
High Speed
45°F (25°C)
Rise
Unit Size (MBTUh)
30 45 60 75 100 125 150
Feet (Meters)
5 (1.5)
X 8 (2.4) 11 (3.4) 13 (4.0) 12 (3.7) 13 (4.0) 13 (4.0)
—
Y 19 (5.8) 28 (8.5) 30 (9.1) 30 (9.1) 32 (9.8) 33 (10.1)
Z 51 (15.5) 81 (24.7) 105 (32.0) 97 (29.6) 110 (33.5) 113 (34.4)
Downward louver angle 20° 11° 11° 9° 10° 7°
8 (2.4)
X 10 (3.0) 15 (4.6) 17 (5.2) 17 (5.2) 18 (5.5) 19 (5.8) 18 (5.5)
Y 19 (5.8) 29 (8.8) 33 (10.1) 33 (10.1) 34 (10.4) 36 (11.0) 32 (9.8)
Z 48 (14.6) 79 (24.1) 103 (31.4) 95 (29.0) 108 (32.9) 111 (33.8) 107 (32.6)
Downward louver angle 31° 19° 19° 16° 17° 13° 19°
10 (3.0)
X 11 (3.4) 16 (4.9) 19 (5.8) 19 (5.8) 20 (6.1) 21 (6.4) 19 (5.8)
Y 19 (5.8) 30 (9.1) 34 (10.4) 33 (10.1) 36 (11.0) 37 (11.3) 34 (10.4)
Z 44 (13.4) 78 (23.8) 100 (30.5) 94 (28.7) 106 (32.3) 109 (33.2) 104 (31.7)
Downward louver angle 39° 24° 23° 20° 21° 17° 24°
*See Figure 1.
GENERAL INFORMATION—CONTINUED
Heater Location—Continued
Heater Throw Distances with Standard Horizontal Louvers—Continued
—Continued
