9
UBXC-UDXC-IOM (01-24) 1042980-0
Table 2. Heater Throw Distance (Model UBXC)
H*
(Feet
(Meters))
Distance* or Angle
High Speed
45°F (25°C)
Rise
Unit Size (MBTUh)
30 45 60 75 100 125 150
Feet (Meters)
12 (3.7)
X 11 (3.4) 17 (5.2) 21 (6.4) 20 (6.1) 22 (6.7) 23 (7.0) 21 (6.4)
Y 17 (5.2) 30 (9.1) 35 (10.7) 34 (10.4) 36 (11.0) 39 (11.9) 34 (10.4)
Z 40 (12.2) 75 (22.9) 98 (29.9) 92 (28.0) 104 (31.7) 107 (32.6) 102 (31.1)
Downward louver angle 46° 29° 27° 25° 25° 21° 28°
14 (4.3)
X 9 (2.7) 18 (5.5) 22 (6.7) 21 (6.4) 23 (7.0) 24 (7.3) 22 (6.7)
Y 15 (4.6) 30 (9.1) 34 (10.4) 34 (10.4) 36 (11.0) 39 (11.9) 34 (10.4)
Z 33 (10.1) 72 (21.9) 95 (29.0) 89 (27.1) 102 (31.1) 105 (32.0) 98 (29.9)
Downward louver angle 56° 34° 31° 29° 29° 25° 32°
16 (4.9)
X
—
19 (5.8) 23 (7.0) 22 (6.7) 24 (7.3) 25 (7.6) 22 (6.7)
Y 29 (8.8) 33 (10.1) 33 (10.1) 36 (11.0) 40 (12.2) 33 (10.1)
Z 69 (21.0) 91 (27.7) 86 (26.2) 99 (30.2) 103 (31.4) 94 (28.7)
Downward louver angle 39° 35° 33° 33° 29° 36°
18 (5.5)
X
—
18 (5.5) 21 (6.4) 22 (6.7) 23 (7.0) 26 (7.9) 21 (6.4)
Y 28 (8.5) 33 (10.1) 33 (10.1) 36 (11.0) 39 (11.9) 33 (10.1)
Z 64 (19.5) 86 (26.2) 83 (25.3) 95 (29.0) 101 (30.8) 89 (27.1)
Downward louver angle 44° 40° 37° 37° 32° 41°
H*
(Feet
(Meters))
Distance* or Angle
75°F (42°C)
Rise
80°F (44°C)
Rise
Unit Size (MBTUh)
175 200 225 250 300 350 400
Feet (Meters)
8 (2.4)
X 12 (3.7) 13 (4.0) 13 (4.0) 14 (4.3) 12 (3.7) 13 (4.0) 15 (4.6)
Y 22 (6.7) 24 (7.3) 24 (7.3) 27 (8.2) 21 (6.4) 25 (7.6) 28 (8.5)
Z 69 (21.0) 76 (23.2) 82 (25.0) 95 (29.0) 70 (21.3) 82 (25.0) 95 (29.0)
Downward louver angle 30° 27° 29° 26° 32° 27° 24°
10 (3.0)
X 12 (3.7) 14 (4.3) 12 (3.7) 16 (4.9) 12 (3.7) 14 (4.3) 16 (4.9)
Y 22 (6.7) 24 (7.3) 21 (6.4) 27 (8.2) 21 (6.4) 25 (7.6) 28 (8.5)
Z 65 (19.8) 72 (21.9) 66 (20.1) 91 (27.7) 65 (19.8) 77 (23.5) 92 (28.0)
Downward louver angle 37° 33° 38° 31° 39° 33° 29°
12 (3.7)
X 13 (4.0) 14 (4.3) 12 (3.7) 16 (4.9) 12 (3.7) 14 (4.3) 17 (5.2)
Y 21 (6.4) 23 (7.0) 20 (6.1) 27 (8.2) 19 (5.8) 24 (7.3) 28 (8.5)
Z 59 (18.0) 68 (20.7) 60 (18.3) 86 (26.2) 58 (17.7) 72 (21.9) 88 (26.8)
Downward louver angle 43° 39° 45° 37° 47° 40° 34°
14 (4.3)
X 11 (3.4) 14 (4.3) 11 (3.4) 16 (4.9) 10 (3.0) 14 (4.3) 17 (5.2)
Y 19 (5.8) 22 (6.7) 18 (5.5) 25 (7.6) 17 (5.2) 22 (6.7) 27 (8.2)
Z 52 (15.8) 62 (18.9) 53 (16.2) 80 (24.4) 50 (15.2) 66 (20.1) 82 (25.0)
Downward louver angle 51° 46° 52° 43° 55° 46° 39°
16 (4.9)
X
—
12 (3.7)
—
16 (4.9)
—
13 (4.0) 17 (5.2)
Y 20 (6.1) 23 (7.0) 20 (6.1) 26 (7.9)
Z 53 (16.2) 73 (22.3) 57 (17.4) 76 (23.2)
Downward louver angle 53° 49° 53° 45°
18 (5.5)
X
—
14 (4.3)
—
16 (4.9)
Y 21 (6.4) 24 (7.3)
Z 64 (19.5) 69 (21.0)
Downward louver angle 56° 50°
*See Figure 1.
—Continued
To Next Page
