Chapter 1: Your Product
VENUS X1PRO-E User Manual
values such as resolution and size.
LOGO Button
LOGO load &LOGO Capture shortcut button.
OUT BRIGHT
Shortcut button for output Setting, output Brightness Setting, and 4K Input Signal
switch.
SPLIT Button
Split function button.
LOAD Button
Restores/Loads all current settings with the VENUS X1PRO-E from 1 of the 24
available slots.
Additionally, this button is used for direct numeric entry for numbers 6.
MODULE Buttons
If optional input module is fitted, then these three buttons operate as per Dedicated
Signal Buttons above.
Additionally, these buttons are used for direct numeric entry for numbers 7/8/9.
BLACK Button
Black button.
Additionally, this button is used for direct numeric entry for number 0.
TAKE Button
To preview the selected signal and take it to output.
USB Connector
For system upgrade.
