Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
18
->Standard >>
Split >>
Preview >>
Stand Alone Mode >>
->Advanced >>
语言/Language English
Factory Reset >>
->Standard >>
Split >>
Preview >>
Stand Alone Mode >>
menu.
5
System Mode
Show the default system mode.
6
Output Resolution
Show the current output resolution. To configure output resolutions, use the OUTPUT
menu. A wide range of resolutions are supported – refer to Specification.
If a # symbol is show after the resolution, then a custom resolution is being used.
3.3.2 Understanding the Main Menu
Push the MENU button in the default state and turn the rotary knob, the OLED display will show
the main menus as below:
There are 7 menu items in the main menu, and display in 2 pages. Turn the rotary knob, and
select any menu above, push the rotary knob to confirm, the OLED display will show the
submenu. If push the MENU button, the OLED display will return to the last level menu.
3.3.3 Mode Menu
Standard Mode
Select standard resolution or custom the resolution.
Thirteen Image Select Modes for selection.
For details, please refer to Standard Mode.
Split Mode
Select standard resolution or custom the resolution.
Twelve Split Mode and Multi-Split Mode for selection.
For details, please refer to Split Mode.
