RGBlink VENUS X1 PRO-E - Stand Alone Mode Operation

Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
39
Standard >>
Split >>
Preview >>
->Stand Alone Mode >>
->Output DVI1 >>
Output DVI2 >>
Output DVI3 >>
Output DVI4 >>
->Input Source DVI1
Scale >>
Crop >>
Reset Parameters
->Width 1920
Height 1080
H Pos 0
V Pos 0
3.7 Standard Alone Mode
Each of output channels can have same resolution, individually input signal, scale and position setting.
There is no PIP in this mode.
1. Push the <MENU>, turn the rotary to select <Stand Alone Mode>, push the knob to confirm, enter menus as
follows:
2. Each Output DVI can be set the parameter for input signal, scale and crop.
Input Source: can be DVI, DVI2, DP and any optional input signals.
Scale & Crop: set the Width, Height, H Pos, V Pos and Reset Parameters.
