RGBlink VENUS X1 PRO-E - Split Mode Configuration

Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
28
Output Resolution >>
->Split Mode >>
Multi - Split >>
->Split Mode H 1/2
PIP Config >>
H Total 3840
V Total 1080
Width 1 1920
Details >>
EDID >>
Reset Parameters >>
Output Resolution >>
->Split Mode >>
Multi - Split >>
3.5 Split Mode
Push the [SPLIT] button, and enter to the output mode menus. Turn the rotary knob to select
<SPLIT MODE>, and enter to the menu items as follows:
Output Resolution: Setting same as Standard Mode.
Split Mode: Split mode for One device
Multi-Split: Split mode for 2 or more than 2 devices cascade.
3.5.1 Split Mode
VENUS X1PRO-E equipped with 4K module, and the output resolution can up to 4K×1K.
There are 12 split modes:
H1/2, V1/2, H1/4, V1/4, CROSS, H 2 In/2Out, V 2 In/2Out, H 2 In/3Out, H 2 In/4Out, 3D Normal,
3D Split H 1/2, 3D Split V 1/2.
Realize up to 8K1K, 4K2K, 6K1K single device split.
Follows will provide samples for 3 modes setting: H 1/2, CORSS, H 2 In/3Out.
H 1/2 Split
1. Push the <Menu> button, turn the rotary to select <Split>, push the knob; Or Push the [SPLIT]
button, both ways will enter to the split mode as follows.
2. Select <Split Mode>, press the knob, shows the follows, select H1/2.
