VENUS X1PRO-E User Manual
49
Chapter 6 Appendix
6.1 Specification
DVI Input (Standard)
Number of Inputs
1
Connector
Standard DVI-I socket
Supported Resolution
SMPTE：625/25/50 PAL, 525/29.97/59.94 NTSC,
1080P50/59.94/60 I 1080i50/59.94/60,
720p50/59.94/60
VESA：800×600@60 | 1024×768@60 | 1280×768@60 |
1280×1024@60 | 1600×1200@60 | 1920×1080@60
Signal Level
TMDS pwl, single pixel input,165MHz bandwidth
Format Standard
HDMI 1.3
4K DVI Input (Standard)
Number of Inputs
1
Connector
Standard DVI-I socket
Supported Resolution
SMPTE：625/25/50 PAL, 525/29.97/59.94 NTSC,
1080P50/59.94/60 I 1080i50/59.94/60,
720p50/59.94/60
VESA：800×600@60 | 1024×768@60 | 1280×768@60 |
1280×1024@60 | 1600×1200@60 | 1920×1080@60 | 3840×1080@60 |
3840×2160@30
Signal Level
TMDS pwl, single pixel input,165MHz bandwidth
Format Standard
HDMI 1.4
4K DP Input (Standard)
Number of Inputs
1
Connector
Standard
Supported Resolution
VESA: 3840×2160@24 | 3840×2160@25 | 3840×2160@30 |
4096×2160@24
SMPTE: 625/25/50 PAL, 525/29.97/59.94 NTSC,
1080P50/59.94/60 I 1080i50/59.94/60,
720p50/59.94/60
Supported Bandwidth
21.6Gb/s
Format Standard
DP 1.2
DVI Output (Standard)
Number of Outputs
4
Connector
Standard DVI-I Socket
Signal Level
TMDS pw, 165MHz bandwidth
Supported Resolution
SMPTE：1080P50/60 | 720p50/60
VESA:
