Standard >
Split >>
->Preview >>
Stand Alone Mode >>
->Output Resolution >>
Presentation Mode >>
Switching Time 0.1s
Output Resolution >>
->Presentation Mode >>
Switching Time 0.1s
->Presentation Mode Normal
Image 1 Source DVI1
Width 1300
Height 1080
->H Pos 0
V Pos 0
EDID >>
Reset Parameters
3.6 Preview Mode
Each of two output channels can have individually resolution, Output port DVI 1 & DVI 2 default
as PST output, DVI 3 & DVI 4 default to PGM output.
Scale the image, zoom the image and image quality setting.
1. Push the [MENU] button, turn the rotary knob, select <Preview>.Push the knob button, and
enter to preview mode, the mode including three functions: <Output Resolution>, <Presentation
Mode>, <Switching Time>. turn the rotary knob, select different function to set parameters.
Output Resolution setting same as standard mode.
2. Turn the rotary knob, select <Presentation Mode>.
3. There are four modes, <Normal>, <PIP>, <Split H>, <Split V>, select different mode, items
menus will show as follows:
Normal Modes
