Chapter 3: Using Your Product
VENUS X1PRO-E User Manual
36
->H Pos 0
V Pos 0
Image 2 Source DVI2
Width 1300
->Presentation Mode PIP
Image 1 Source DVI1
Width 1300
Height 1080
->Height 1080
H Pos 650
V Pos 0
EDID >>
Reset Parameters
->Presentation Mode Split H
H Total 3840
V Total 1080
Width 1 1920
Details >>
EDID >>
Reset Parameters
PIP. Set H total, V total, width of each screen according to actual need. Image source setting to
different input source.
Split H
1. Select <Split H>, press the knob, shows the follows.
2. Set H total, V total, width1 of screen according to actual need.
For example, set H total as 3840, V total as 1080, Height 1 is 1080, same with V total.
Set Width 1 as 1920 and Width 2 will be 1920, ( H total <3840> - Width 1 <1920> = Width 2
<1920> ).
As shown in the figure below:
