Chapter 3: Using Your Product

VENUS X1PRO-E User Manual

Reset Parameters:

If image quality distorts by improper operation, it can be recover by reset.

device parameters setting as follows:

Split Mode:

elect the same split mode or same type mode for two devices, e.g. H1/4

H Total: Setting the total Horizontal size, 1

device H size+ 2

device H size, here equals

8*1920=15360

V Total: Setting the total vertical size: 1080

Here Scale H Pos: Equals to =H Total- 1

device Width=15360-7680=7680

Here Scale V Pos: 0 (In horizontal split Mode, same Height )

Here Width: 2

device all output port width 4*1920=7680

Here Height: 1080

Width 1: 1

output port width 1920

Width 2: 2

output port width 1920

Width 3: 3rd output port width 1920

Details: Adjust Layer A to D for Scale or Crop

EDID:

Setting DVI1, DVI2, DP Port to follow other input signal resolution.

Reset Parameters:

If image quality distorts by improper operation, it can be recover by reset.

(3) Finish two VENUS X1PRO-E Split mode H1/4 setting, come true 16K1K split.
