->Multi - Split Source DVI1
Sync ON
Split Mode >>
->Split Mode H 1/4
H Total 15360
V Total 1080
Here Scale H Pos 0
->
Here Scale V Pos 0
Here Width 7680
Here Height 1080
Width 1 1920
->Width 2 1920
Width 3 1920
Details >>
EDID >>
->
Reset Parameters
Multi - Split Source: Two VENUS X1PRO-E select the same source from input signal. E.g. DVI1
Sync: Enable the Sync function for all connecting devices.
Split Mode: Same as single device mode.
(2) Select <Split Mode> button, push the knob to confirm, enter to the menu items as follows:
1
st
device parameters setting as follows:
Split Mode:
S
elect the same split mode or same type mode for two devices, e.g. H1/4
H Total: Setting the total Horizontal size, 1
ST
device H size+ 2
nd
device H size, here equals
8*1920=15360
V Total: Setting the total vertical size: 1080
Here Scale H Pos: 1
st
device H Pos=0
Here Scale V Pos: 1st device V Pos= 0
Here Width: 1
st
device all output port width 4*1920=7680
Here Height: 1080
Width 1: 1
st
output port width 1920
Width 2: 2
nd
output port width 1920
Width 3: 3rd output port width 1920
Details: Adjust Layer A to D for Scale or Crop
EDID:
Setting DVI1, DVI2, DP Port to follow other input signal resolution.
