6
“L”
“W”
“H”
A
I
R
D
I
S
C
H
A
R
G
E
ALLOW 60” [1524mm]
OF CLEARANCE
AIR INLET LOUVERS ALLOW
6” [152mm] Min. OF CLEARANCE ALL SIDES
12” [305mm] RECCOMMENDED
SERVICE PANELS/
INLET CONNECTIONS / HIGH & LOW
VOLTAGE ACCESS
ALLOW 24” [ 610 mm] OF CLEARANCE
ST-A1226-02-00
ALLOW 60" [1524mm] OF
CLEARANCE
SERVICE PANELS/
INLET CONNECTIONS /
HIGH & LOW VOLTAGE
ACCESS ALLOW
24" [610 mm] OF
CLEARANCE
AIR INLET LOUVERS ALLOW
6" [152 mm] OF CLEARANCE ALL SIDES
12" [305 mm] RECOMMENDED
3.0 UNIT SPECIFICATIONS
Unit Specications
3.2 Electrical and Physical Data
Rev. 07/15 ELECTRICAL
Model
Number
(-)P17
Phase
Frequency (Hz)
Voltage (Volts)
Fan Motor
Full Load
Amperes (FLA)
Minimum
Circuit
Ampacity
Amperes
Rated Load
Amperes
(RLA)
Locked
Rotor
Amperes
(LRA)
Minimum
Amperes
Maximum
Amperes
24 1-60-208/230 16/16 35 0.8 21/21 25/25 35/35
36 1-60-208/230 16.3/16.3 35 0.8 22/22 30/30 35/35
48 1-60-208/230 21.6/21.6 35 0.9 28/28 35/35 45/45
60 1-60-208/230 33.8/33.8 50 1.0 44/44 50/50 60/60
Rev. 07/15 PHYSICAL
Model
Number
(-)P17
Outdoor Coil
Refrig. Per
Circuit Oz. [g]
Weight
Face Area
Sq. Ft. [m
2
] No. Rows CFM [L/s] Net Lbs. [kg] Shipping Lbs. [kg]
24 19.76 1 3250 [1533] 124 [3515] 223 230
36 19.76 1 3270 [1543] 134 [3798] 223 230
48 24.23 1 4000 [1887] 202 [5726] 250 257
60 28.26 1 4200 [1982] 204 [2948] 282 289
Compressor Fuse or HACR Circuit Breaker
(-)P17 24 36 48 60
Height “H” inches (mm) 35 (889) 35 (889) 39 (991) 45 (1143)
Length “L” inches (mm) 33.75 (857) 33.75 (857) 35.75 (908) 35.75 (908)
Width “W” inches (mm) 33.75 (857) 33.75 (857) 35.75 (908) 35.75 (908)
DIMENSIONAL DATA
