supply type, the special testing switching power is needed. （ 24V origin detecting
switch is the best choice）
RichAuto-A58 realizes its control through the connection between the interface
board and CNC machine. Interface board terminal can be divided into input terminal
and output terminal：
Input terminal：
INPUT SIGNAL （Input signal terminal）
DC24V（Power supply terminal）
Output terminal：
X_AXIS（X pulse output terminal & encoder output terminal）
Y_AXIS（Y pulse output terminal）
Z_AXIS（Z pulse output terminal）
C_AXIS（C pulse output terminal）
OUTPUT SIGNAL（Output signal terminal）
ANALOG（Analog quantity output terminal）
PWM（PWM output terminal）
INPUT SIGNAL Terminal
DC24V Power supply wiring
INPUT SIGNAL Wiring
