SH-P1 Training
33
Slide 33
Circumference of Rollers
Abnormal image repeating at intervals may be
related to a roller with a matching circumference.
113 mm: Feed roller
94 mm: By-pass feed roller
51.8 mm: Transport rollers
50.7 mm: Registration rollers
96 mm: Drum
50 mm: Transfer roller
117.8 mm: Hot roller
100.5 mm: Pressure roller
43.4 mm: Fusing exit rollers
44 mm: Exit rollers
45.5 mm: Duplex relay rollers
52 mm: Development roller
This list may be useful during troubleshooting.
