3.
ADF pick-up roller lift motor [A] (
×2,
×1, timing belt×1).
4.
ADF transport motor [A] along with the bracket (
×2,
×1, timing belt×1).
ADF Bottom Plate Lift Motor
1.
ADF entrance motor along with the frame (
page 46
).
Electrical Components
31
32
34
