3. Lift-Up Sensor [A] along with the bracket ( ×1, ×1).
Original Set Sensor
1. ADF front cover (page 15).
2. Original feed unit (page 19).
3. Remove the screw and raise the original tray [A] ( ×1).
4. Original set sensor [A] ( ×1, ×1).
