Original Feed Drive
ADF Entrance Motor
1. ADF rear cover (page 16).
2. ADF entrance motor [A] ( ×2, ×1, timing belt×1).
ADF Scanning Motor
1. ADF entrance motor along with the frame (page 46).
1. Replacement and Adjustment
46
