Ricoh D683 User Manual

Version Section Details
Replacement and Adjustment >
Electrical Components > ADF Pick-
up Roller Lift Motor / ADF Transport
Motor
Added item needs to be removed in Step 2.
Replacement and Adjustment >
Electrical Components > Original
Registration Sensor
Deleted unnecessary part in Step 4.
Replacement and Adjustment >
Electrical Components > Original
Exit Sensor
Added new steps into Step 1 and Step 2.
Modified the description of Step 5.
Replacement and Adjustment >
Electrical Components > Separation
Sensor / Skew Correction Sensor
Deleted some steps.
Replacement and Adjustment >
Electrical Components > Original
Set Sensor
Replacement and Adjustment >
Electrical Components > A4 LEF/LT
LEF Sensor
Replacement and Adjustment >
Original Feed Drive > ADF Entrance
Motor
Modified the procedure.
Replacement and Adjustment >
Original Feed Drive > ADF Exit
Motor
Added Step 3.
Replacement and Adjustment >
Original Feed Drive > ADF Feed
Motor
Modified Step 2 and its picture.
2
