5. Press [Auth. Info], and then press [ Next].
6. Press [Specify Other Auth. Info] on the right side of "Folder Authentication".
When [Do not Specify] is selected, the SMB User Name and SMB Password that you have
specified in "Default User Name / Password (Send)" of File Transfer settings are applied.
7. Press [Change] under "Login User Name".
8. Enter the login user name of the destination computer, and then press [OK].
9. Press [Change] under "Login Password".
10. Enter the password of the destination computer, and then press [OK].
11. Enter the password again to confirm, and then press [OK].
12. Press [Folder].
13. Check that [SMB] is selected.
14. Press [Change] or [Browse Network], and then specify the folder.
To specify a folder, you can either enter the path manually or locate the folder by browsing the
network.
15. Press [Connection Test] to check the path is set correctly.
16. Press [Exit].
If the connection test fails, check the settings, and then try again.
17. Press [OK].
18. Press [User Tools] ( ) on the top right of the screen.
6. Scan
104

Ricoh MP 402SPF Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Maximum Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	1, 600 sheets
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Maximum Paper Size	A4
Warm-up Time	21 seconds
Memory (RAM)	2 GB
Fax Transmission Speed	33.6 Kbps
Copy Resolution	600 x 600 dpi
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB, Ethernet, Wi-Fi
Control Panel	Touchscreen
Mobile Printing	Yes
Hard Disk Drive	320 GB (Optional)
Network Connectivity	Ethernet
Print Speed	Up to 42 ppm (Letter)
Copy Speed	Up to 42 cpm (Letter)
