Ricoh SP 211SF - Interior; Control Panel

Interior
DCT064
1
1. Print Cartridge
A replacement consumable that is required to make prints on paper. For details about replacing the cartridge,
see page 203 "Replacing the Print Cartridge".
MF
Control Panel
On the Right
1 2 3 4 5
6 7 8 9
DCT890
1. Screen
Displays current status and messages.
2. Scroll Keys
Press these keys to move the cursor in each direction.
Guide to Components
