Ricoh SP 3600SF - Copying Onto Custom Size Paper from the Bypass Tray

Copying onto Custom Size Paper from the
Bypass Tray
Paper that has a horizontal length of 60.0–216.0 mm (2.37–8.50 inches) and a vertical length of
127.0–900.0 mm (5.00–35.43 inches) can be fed in from the bypass tray.
Press the [Copy] key, and then select the setting items using the [
] or [ ] key.
1. Load the paper face up in the bypass tray
2. Press [ ]
DBH089
3. Select [Paper Size] Press [OK]
4. Select [Custom Size] Press [OK]
5. Enter the horizontal size with the number keys Press [OK]
6. Enter the vertical size with the number keys Press [OK]
7. Press [ ]
8. Select [Paper Type] Press [OK]
9. Specify the type of the paper as necessary Press [OK]
10. Place the originals Press [Start]
When the copy job is finished, press the [Reset] key to clear the settings.
Copying onto Custom Size Paper from the Bypass Tray
45
