Ricoh SP6330 - Page 149

9. Push the lock levers of the fusing unit down until they click.
BVN131
10. Position the rear cover horizontally and align it with the grooves in the printer's interior.
BVN132
11. Close the rear cover.
BVN121
Replacing the Maintenance Kit
147
6
