3. Connect the other end of the cable to the network, such as a hub.
• The printer's Ethernet and USB port B are not available when the Gigabit Ethernet board is attached
to the printer.
• "Network Connection", Software Guide.
• p.43 "Installing the Interface Units"
Reading the LED Lamps
For the standard Ethernet port
BTH021S
1
2
1. Indicator (yellow)
Lights up yellow when 100 BASE-TX is in operation. Goes off when 10 BASE-T is in operation.
2. Indicator (green)
Lights up green when 10 BASE-T is in operation. Goes off when 100 BASE-TX is in operation.
