PRODUCT DESCRIPTION
2.75”
(*)
79.21”
83”
60.8”
11”
Ø1.5”
50.8”
8.8”
11.25”
6.7”
33.3”
Ø4”
7.47” 12.1”
Ø8”
Ø1.57”
Ø2.36”
4.5”
5.8”
12.12” 10.3”
Ø4”
Ø8”
7.6”
ARRAY AR 2000
Dimensions are in inches
(*) Mounting feet may be removed during installation to reduce the overall height by 2”. Feet must be re-installed once boiler is in
its nal location.
