Riello Array AR 2000 User Manual

61
SHUTDOWN
61
APPENDIX
APPENDIX
APPENDIX I - VENTING SIZE DATA
While there is a positive ue pressure during operation, the combined pressure drop of vent and combustion air systems must not
exceed the following equivalent length:
MODEL
PIPE SIZE - 6" PIPE SIZE – 8”
MAX equiv. mt MAX equiv. ft MAX equiv. mt MAX equiv. ft
AR 1000 30 100 - -
AR 1500 30 100 - -
AR 2000 - - 30 100
Fittings as well as pipe lengths must be calculated as part of the equivalent length, according to the following table:
MODEL
45° ELBOW - 6” 90° ELBOW - 6"
MAX equiv. mt MAX equiv. ft MAX equiv. mt MAX equiv. ft
AR 1000 1.5 5 1.8 6
AR 1500 1.5 5 1.8 6
MODEL
45° ELBOW - 8” 90° ELBOW - 8"
MAX equiv. mt MAX equiv. ft MAX equiv. mt MAX equiv. ft
AR 2000 2.1 7 2.75 9
Data for Venting size
ARRAY AR 1000
T supply / return (F°) - 176 / 140 T supply / return (F°) - 104 / 86
Maximum Input Minimum Input Maximum Input Minimum Input
CO
2
9% 9% 9% 9%
Exhaust gas mass (weight) 0.26 lb/s 0.02 lb/s 0.26 lb/s 0.02 lb/s
Flue temperature 161.6 °F 143.6 °F 107.6 °F 89.6 °F
Max. pressure at boiler exit @ high re
condition
0.81 in H
2O 202 Pa 0.08 in H2O 19 Pa 0.90 in H2O 224 Pa 0.16 in H2O 40 Pa
ARRAY AR 1500
T supply / return (F°) - 176 / 140 T supply / return (F°) - 104 / 86
Maximum Input Minimum Input Maximum Input Minimum Input
CO
2
9% 9% 9% 9%
Exhaust gas mass (weight) 0.4 lb/s 0.02 lb/s 0.4 lb/s 0.02 lb/s
Flue temperature 161.6 °F 143.6 °F 107.6 °F 89.6 °F
Max. pressure at boiler exit @ high re condition 0.70 in H2O 174 Pa 0.08 in H2O 19 Pa 0.79 in H2O 197 Pa 0.16 in H2O 40 Pa
ARRAY AR 2000
T supply / return (F°) - 176 / 140 T supply / return (F°) - 104 / 86
Maximum Input Minimum Input Maximum Input Minimum Input
CO
2
9% 9% 9% 9%
Exhaust gas mass (weight) 0.52 lb/s 0.02 lb/s 0.52 lb/s 0.02 lb/s
Flue temperature 161.6 °F 143.6 °F 107.6 °F 89.6 °F
Max. pressure at boiler exit @ high re condition 0.75 in H2O 187 Pa 0.1 in H2O 25 Pa 0.84 in H2O 209 Pa 0.18 in H2O 45 Pa
Cascade Venting of Multiple Boiler Installations
When multiple boilers of the same model size are installed within a common room it is permissible to cascade the venting connecting all
boilers to a single exhaust system. No more than eight (8) boilers should be cascade vented together.
The boiler/ vent installation must be in compliance with ANSI Z223.1/ NFPA 54 and all local, state, and federal regulations for building code.
Venting system shall be designed to maintain suitable vent pressure at the boiler exhaust collar.
For a list of suitable venting materials consult the installation manual section: “4.15 Venting” page 26
Adapters are available for various brands of venting materials. Consult the factory for a list of available adapters.
Venting components from different manufacturers shall not be mixed.
Adequate combustion air must be supplied to the boiler to ensure safe operation. A properly sized direct connected common combustion
air duct may be used for sealed combustion air to the boiler cascade.
For additional information regarding combustion air supply consult the installation manual section: “4.16 Combustion Air”
Prior to installing a permanent vent system refer to the Installation Manual, ANSI Z223.1/ NFPA 54, and all local, state, and federal regulations
for building code to ensure compliance with the requirements of these articles.
