PRESENTATION
1. RS232 serial communication port
2. Cooling fans
3. Telephone/modem protection
4. Input thermal protection
5. IEC mains input plug
6. IEC output sockets (max 10A)
7. Communication expansion slot
8. Battery expansion connector
9. IEC 16A output socket
10. Output socket fuse boxes
Dialog Plus 200 ER
Dialog Plus 300 / 300 ER
