rigert Ltd., Stairlifts
Operating manual
Nr.: AW4231
CH-6405 Immensee
Fault finding PEGASUS-NOVA-mps2
Date: 13.03.06
Page: 12/22
4.1.2 Communication with call stations
Take off the front cover of the call station which does not show communication
Check whether call station code complies with the number of the landing
Check whether LED’s are lighted permanently
If this is ok, take off the call station completely and connect it directly to the main controller
if function ok: wiring faulty
if function not ok: exchange call station PCB
LED ON:
tension present
LED ON:
communication ok
Code switch of
call station
(numbered from
bottom (=1), to top
of installation
