rigert Ltd., Stairlifts
Operating manual
Nr.: AW4231
CH-6405 Immensee
Fault finding PEGASUS-NOVA-mps2
Date: 13.03.06
Page: 16/22
7.1.4 Check platform position of carriage
Check whether the controller recognizes the various positions of the platform.
Run the carriage onto a landing (maybe hand winding required)
Press the emergency stop (display changes from “ok” to “em”)
Now, fold up the platform (no damage will occur !)
Check the display for “PFZu”
Fold fully down the platform (leave the barriers down)
Check the display for “PFzws”
Fold up barriers (as if a user would like to board).
Unlock the emergency stop
Switch off the main controller for at least 20 sec. And switch it on again
Press one of the directional buttons on the hand hold control unit in direction to the
travelway end (if carriage on a mid-landing, press the open barrier button).
Check the display for “PFZus”
Travel a bit away from the landing (maybe hand winding required) and do the same thing
again. In this case, it does not matter which travel directional button you press.
Check the display for “PFTrsp”
If ok, proceed to point 8, otherwise to point 7.2.2
