rigert Ltd., Stairlifts
Operating manual
Nr.: AW4231
CH-6405 Immensee
Fault finding PEGASUS-NOVA-mps2
Date: 13.03.06
Page: 18/22
7.2 Search for faults
7.2.1 Safety switches
“< , v, > “ Identifies a safety switch within safety circuit 1.
The controller recognizes the single switch.
“ 2 ” Identifies a safety switch within safety circuit 2.
The controller recognizes only safety circuit 2.
Check
safety switch (switch test):
Switch OFF controller on main switch
Change Dip switches 6 and 8 on carriage PCB to ON
Switch ON controller on main switch
Activate with a screw driver all safety switches in safety circuit 1 (beep = this switch ok !)
Activate now one switch of the safety circuit 2 (beep = all switches ok !)
If no beep circuit 1: check the switch in detail and its wiring (check also diode built into
loom of S14/S15)
If no beep circuit 2:
Switch OFF main switch
Unplug looms on carriage PCB
Check all single switches within circuit 2 with a continuity checker.
If no continuity – change the switch
7.2.2 Position switches
The controller needs to receive the correct information as to define the state of “PFTrsp”,
“PFZus” and “Pfzu” – otherwise the controller shows “PFzws”.
Check
position switch (switch test):
Switch OFF controller on main switch
Change Dip switches 6 and 8 on carriage PCB to ON
Switch ON controller on main switch
Activate with a screw driver all position switches (beep = this switch ok !)
If no beep: check the switch in detail and its wiring
Switch Signification Platform
down
Platform
upfolded
S11
Platform folded up Continuity No continuity
S12
Platform folded down No continuiuty Continuity
S25
Platform at 25° No continuity Continuity
S45 a + b
Barrier locking upwards Continuità No continuity
S46 a + b
Barrier locking downwards Continuità No continuity
S16 + S17
Barrier arm down position Continuità No continuity
