Frequency range: 0.06 to 35 MHz
Frequency entry: 1 kHz resolution
Measurement for 25, 50, 75 and
100-Ohm systems
SWR measurement range:
• 1 to 100 in numerical modes
• 1 to 10 in chart modes
SWR display: numerical or analog
indicator
R and X range:
• 0…10000, -10000…10000 Ohm
in numerical modes
• 0…1000, -1000…1000 Ohm in chart
modes
Display modes:
• SWR, return loss, R, X, Z, L, C
at single frequency
• SWR chart, 100 points
• R, X chart, 100 points
Optional open-short-load calibration.
RF output:
• Connector type: UHF (SO-239)
• Output signal shape: square, 0.06 to
35 MHz
• Output power: +13 dBm (at 50 Ohm
load)
Power:
• Two 1.5V alkaline batteries, type AA
• Two 1.2V Ni-MH batteries, type AA
• Max. 4 hours of continuous
measurement, max. 2 days in stand-
by mode when fully charged batteries
are used
• When the analyzer is connected to a
PC or a DC adapter with USB socket, it
takes power from these sources
Interface:
• 320×240 color TFT display
• 6x3 keys on the water-proof keypad
• Multilingual menus and help screens
• USB connection to a personal
computer
Dimensions: 103 × 207 × 37 mm
(4.1 × 8.1 × 1.4 in)
Operating temperature: 0…40 °C
(32…104 °F )
Weight: 310 g (10.9 oz) w/o batteries
Warranty: 2 years
RigExpert AA-35 ZOOM is
made in Ukraine.
24
Annex 1
Specifications
