Rigol DG2000 Series User Manual

RIGOL
© 2006 RIGOL Technologies, Inc
User’s Guide for DG2000 Series
2-13
Term Explanation:
Pulse Width:
Positive Pulse Width: the time span between thresholds of 50% of the rising edge
amplitude to the next 50% of the falling edge amplitude;
Negative Pulse Width: the time span between thresholds of 50% of the falling
edge amplitude to the next 50% of the rising edge amplitude.
Edge Time:
The time span between the thresholds of the 10% to 90% of the rising edge
amplitude is called Rising Time.
The time span between the thresholds of the 10% to 90% of the falling edge
amplitude is called Falling Time.
The Rising Time and the Falling Time together are called Edge Time.
