User’s Guide for DG2000 Series
2-42
To Generate Sweep
In the frequency sweep mode, the function generator “sweep” from the start
frequency to the stop frequency at the sweep rate you specify. Sweeping can be
generated by Sine, Square, Ramp or Arbitrary Waveforms (Pulse, Noise and DC are not
allowed).
Figure 2-55 The Setting Interface of Sweep Waveform
Press Sweep button, in the Normal Mode, the operation menu will appear on the
bottom of the screen, see figure 2-56. Set the Waveform parameters by using the
operation menu.
Figure 2-56 The Operation Menu
