Table 2-21 The Menu Explanations of the Sweep Parameters
Function
Menu
Settings Explanation
Linear/
log
Set the Sweep frequency with linear change
Set the Sweep frequency with logarithmic change
Start/
Center
Set the Start Frequency of the Sweep
Set the Center Frequency of the Sweep
Stop
Span
Set the Stop Frequency of the Sweep
Set the Frequency Span of the Sweep
Time
Set the Time Span of the Sweep for which the Frequency
changes from the Start Frequency to Stop Frequency.
Source
Int: Choose Internal Source
Ext: Choose External Source, use the [Ext
Trig/FSk/Burst] connector in the rear panel
Manual: Choose External Source, set the start and stop
time by hand
TrigOut
: Signal Triggered at Rise Edge
: Signal Triggered at Fall Edge
Off: Turn off Trigger Setting
Trigger
Finish Setting
