User’s Guide for DG2000 Series
2-46
Set the N-Cycle Burst
Press Burst Æ NCycle , enter the following menu.
Figure 2-59 The Operation Menu
Table 2-22 The Menu Explanations of N-Cycle Burst
Function
Menu
Settings Explanation
N-Cycle Set the N-Cycle Mode
Cycles/
Infinite
Set the Number of the bursts in a N-Cycle
Set the Number of the bursts in a N-Cycle
to be infinite
Phase Set the Start Phase of the Burst
Period Set the Period of the Burst
Delay Set the Delay of the burst
Source
Int: Choose Internal Source
Ext: Choose External Source, use the [ Ext
Trig/FSk/Burst] connector in the rear
panel
Manual: Choose External Source, set the
start and stop time by hand
TrigOut
: Signal Triggered at Rising Edge
: Signal Triggered at Falling Edge
Off: Turn off Trigger Setting
Trigger
Finish Setting
