RIGOL Chapter 5 Modulated Waveform Output
DG4000 User's Guide
To Set the OSK Rate
When internal source is selected, press Rate to set the OSK rate.
Use the numeric keyboard or direction keys and knob to input the desired
frequency value.
The frequency range is from 2mHz to 1MHz and the default is 1kHz.
To Set the Oscillate Period
Oscillate period is the oscillation period of internal crystal oscillator. The settable
range of the oscillate period is related to the OSK rate currently selected. Press
OscTime to highlight it and use the numeric keyboard or direction keys and knob
to input the desired period. The default range is from 8ns to 499.75μs.
