Chapter 2 Basic Waveform Output RIGOL
DG4000 User's Guide
To Select Basic Waveform
DG4000 can output 5 kinds of basic waveforms including Sine, Square, Ramp,
Pulse and Noise. At start-up, Sine is selected by default.
1. Sine
Press Sine at the front panel to select sine waveform and the backlight of the
button turns on. At this point, "Sine" and the parameter setting menu of sine
waveform are displayed on the right of the user interface.
2. Square
Press Square at the front panel to select square waveform and the backlight
of the button turns on. At this point, "Square" and the parameter setting menu
of square waveform are displayed on the right of the user interface.
3. Ramp
Press Ramp at the front panel to select ramp waveform and the backlight of
the button turns on. At this point, "Ramp" and the parameter setting menu of
ramp waveform are displayed on the right of the user interface.
4. Pulse
Press Pulse at the front panel to select pulse and the backlight of the button
turns on. At this point, "Pulse" and the parameter setting menu of pulse are
displayed on the right of the user interface.
5. Noise
Press Noise at the front panel to select noise and the backlight of the button
turns on. At this point, "Noise" and the parameter setting menu of noise are
displayed on the right of the user interface.
