Chapter 10 Utility Functions and System Settings RIGOL
DG4000 User's Guide
To Configure the Remote Interface
DG4000 is configured with USB and LAN interfaces and supports users to
configure the interface parameters for remote communication.
Press Utility I/O Config to open the I/O setting menu and set the LAN
interface parameters for remote communication or select the type of device
connected to the USB interface.
LAN Setting
Press Utility I/O Config LAN to open the LAN parameters configuration
interface as shown in the following figure. Users can examine network status and
configure network parameters.
Figure 10-3 LAN Setting Interface
Current IP Configure Mode
Network Status
IP Configure Mode status
MAC Address
VISA Descriptor
To Next Page
