Rigol DG800 Series User Manual

RIGOL Chapter 3 Remote Control
3-2 DG800 User's Guide
Remote Control via USB
1. Connect the device
Use the USB cable to connect the rear-panel USB DEVICE interface of the signal
generator to the USB HOST interface of the PC.
2. Search for the device resource
Start up the Ultra Sigma and the software will automatically search for the
generator resources currently connected to the PC. You can also click
to search the resources.
3. View the device resource
The resources found will appear under the "RIGOL Online Resource" directory,
and the model number and USB interface information of the instrument will also
be displayed.
For example, DG832 (USB0::0x1AB1::0x0642::DG80000000001::INSTR).
4. Communication test
Right-click the resource name "DG832
(USB0::0x1AB1::0x0642::DG80000000001::INSTR)" and select "SCPI Panel
Control" to turn on the remote command control panel, through which you can
send commands and read data. For details about the SCPI commands and
programming, refer to
DG800 Programming Guide .
Remote Control via LAN
1. Connect the device
Use the USB-LAN interface converter to extend the LAN interface for the signal
generator. Use the network cable to connect the signal generator to your local
area network (LAN).
2. Configure network parameters
Configure the network parameters of the signal generator according to "To Set
the LAN Parameters".
3. Search for the device resource
Start up Ultra Sigma and click . The window as shown in figure (a)
is displayed. Click and the software searches for the instrument
resources currently connected to the LAN and the resources found are displayed
at the right section of the window as shown in figure (b). Click to
add it.
