To Enable Channel Output
After configuring the parameters of the waveform selected, enable the channel to
output the waveforms.
Before enabling channel output, you can also tap or and
then tap the corresponding menu label in the channel setting interface to set the
parameters related with the channel output. For details, refer to descriptions in
"Channel Setting".
Press Output1 or Output2 on the front panel, and then the backlight turns on. You
can also tap the channel output configuration status bar or
enable the channel output in the channel setting interface. When the channel status
bar is highlighted, (i.g. ), the configured waveforms are output from the
corresponding output connector on the front panel.
